Lightway 3

Downlight - Recessed Trimless
The downlight dash is a modern concept of glare-free downlight with square distribution. This elegant luminaire is designed to host multiple reflectors of different beam angles, generating a perfect and flawless square distribution, ideal for diverse general lighting applications.

• Clean square light distribution from 25mm round aperture reflectors. The optimal beam angle over field angle ratio offers a highly-uniform horizontal surface
• Flexibility of mounting height with 3 beam angles
• Homogeneous color mixing within one reflector
• Glare-free illumination (UGR<0) for narrow beam,(UGR<14) for medium beam and (UGR<19) for wide beam at Flux =< 650 lm/module.
Product Specifications
  • Ambient lighting product with extruded aluminum body.
  • Finishes in black smooth, white smooth, gray smooth, black textured, white textured and custom colors upon request.
  • Used in indoor environments, recessed trimless in gypsum surface.
  • Width of 35mm, height of 65mm and length ranging from 300 to 3000mm with an increment of 300mm.
  • Delivered luminous output from 350lm to 2700lm.
  • Available Color temperatures (CCT): 2,700K - 3,000K - 4,000K and tunable white (2,700K - 5,000K).
  • Color rendering index CRI 90+.
  • Light emission square beam: 36°, 50° and 60°.
  • Cutout: length + 3mm / width 40mm / depth 92.5mm.
Polar Curve
Narrow Beam, 36° / LOR: 70.3%
Medium Beam, 50° / LOR: 90.4%
Wide Beam, 60° / LOR: 88.5%
Section Drawing
