Lightway 6 - Outdoor

Cut-Off Washer - Inground Deep
The Lightway 6 Inground Cut-Off washer is developed for beautiful lighting in harsh environmental conditions. Made from extruded aluminum, this IP67 element marks a breakthrough in wall washing illumination as it offers different outputs with a flawless surface uniformity while blocking the backward and longitudinal light spill. It is glare- and light-pollution free.
• True wall wash distribution. Vertical light uniformity (1:4)
• Optimized cut-off: blocking the backward and longitudinal light spill (glare-free)
• Homogeneous color mixing within one reflector cell
• A minimum of 10 cm from side walls to prevent unwanted light spillage
• IK10

Build Your Product Spec Sheetdownload
Product Specifications
  • Washer lighting product with extruded aluminum body.
  • Finishes in black smooth, white smooth, gray smooth and custom colors upon request.
  • Used in outdoor environments, recessed deep in concrete surface.
  • Width of 90mm, depth of 133mm and length ranging from 300 to 1500mm with an increment of 300mm.
  • Delivered luminous output per meter from 1600lm to 3200lm.
  • Available Color temperatures (CCT): 2,700K - 3,000K and 4,000K
  • Color rendering index CRI 90+.
  • IK10


Polar Curves
polar_curves
LOR: 58.85%
Section Drawing
section_drawing

Mounting Ratio
mounting_ratio

Setback from the wall is defined by wall texture and height. Consult factory for optimal setback according to your project conditions.
