Lightway 6
Cut-Off Washer - Pendant Direct / Indirect
The Lightway 6 Direct/Indirect linear system offers numerous combinations of optics and output options. A well-lit ceiling improves the look of the workspace without having to compromise on the efficiency.
The cut-off washer, for direct emission, marks a breakthrough in wall washing illumination as it offers different outputs with a flawless surface uniformity while blocking the backward and longitudinal light spill. It is glare- and light-pollution free.
• True wall wash distribution. Vertical light uniformity (1:4)
• Optimized cut-off: blocking the backward and longitudinal light spill (glare-free)
• Homogeneous color mixing within one reflector cell
• A minimum of 10 cm from side walls to prevent unwanted light spillage
Product Specifications
- Washer lighting product with extruded aluminum body.
- Finishes in black smooth, white smooth, gray smooth, black textured, white textured and custom colors upon request.
- Used in indoor environments, pendant from stone, concrete, metal or wood surfaces.
- Width of 66mm, height of 103mm and length ranging from 300 to 3000mm with an increment of 300mm.
- Delivered luminous output per meter from 1950lm to 3600lm.
- Available Color temperatures (CCT): 2,700K - 3,000K - 4,000K and tunable white (2,700K - 5,000K).
- Color rendering index CRI 90+.
Direct Polar Curve
Indirect Polar Curve
Section Drawing
Mounting Ratio
Setback from the wall is defined by wall texture and height. Consult factory for optimal setback according to your project conditions.
